Specifications:
1, Transmission Frequency: ISM 2400~2483.5 MHz
2, Transmission Power: 17dBm
3, Unobstructed Effective Range: 160ft/50m indoor/850ft/260m outdoor, line of sight
4, Spread Spectrum: AFH & TDMA
5, Modulation Mode: GFSK
6,Operating Temperature: 14 ~ 122° Fahrenheit/- 10 ~ +50° Celsius
7, Operating Humidity: <85%
MONITOR
1, LCD Size: 3.2″
2, Resolution Supported: 320 x 240
3, Receiving Sensitivity: -90dBm
4, Consumption Current (Max.): 200mA
5, Battery: Li-polymer / 750mAh,3.7V
6, Power Supply: 5V/500mA DC
7,Dimensions (W x H x D): 70mm x 120mm x 17mm
8, Weight: 0.08kg
CAMERA
1, Image Sensor: CMOS
2, Total Picture Pixels: 640 x 480 px
3, Minimum Illumination: 0 Lux (IR on)
4, Night Vision Distance: 15 FT (5m)
5, View Angle: Diagonal 45°
6, Power Consumption (Max.): 200 mA
7, Power Supply: 5V/500mA DC
8,Dimensions (W x H x D): 67mm x 106mm x 67mm
9, Weight: 0.1 kg
